MSI PRO Z790-A WIFI DDR4 LGA 1700 Intel Z790 SATA 6Gb/s DDR4 ATX Motherboard

  • Supports 12th/13th Gen Intel Core Processors, Pentium Gold and Celeron Processors.
  • DDR 4 Dual Channel.
  • Lightning Gen 5: The latest PCIE 5.0 solution with up to 128 GB/s bandwidth for maximum transfer speed.
  • Wifi-6E: the latest wireless solution support 6GBz spectrum, MU-MIMO and BSS color technology.
  • Lightning USB 20G: Built-in USB3.2 Gen 2X2.
  • Extended Heatsink Design: MSI extended PWM heatsink and enhanced circuit designs ensures even high-end processors to run in full speed.
  • M.2 Shield FROZR: Strengthened build- in M.2 thermal solution. Keeps M.2 SSDs safe.
  • 2.5G network solution: Featuring premium 2.5 LAN to delivery better network experience.
  • Pre-Installed I/O Shielding: better EMI protection and more convenience for installation.
  • Frozr Al Cooling: with Premium layout and fully digital power design to support more cores and provide better performance.

Summer Shopping Season Sale

Hurry and get discounts on all products up to 2%

02_sale

₨ 83,000

Out of stock

Out of stock

Add to compare
Add to wishlist

Payment Methods:

Description

MSI PRO Z790-A WIFI DDR4 LGA 1700 Intel Z790 SATA 6Gb/s DDR4 ATX Motherboard Price in Pakistan Specs

Model
Brand MSI
Model PRO Z790-A WIFI DDR4
Supported CPU
CPU Socket Type  LGA 1700
CPU Type Supports 13th / 12th Gen Intel Core Processors, Intel Pentium Gold, Celeron Processors
Chipsets
Chipset  Intel Z790
Memory
Number of Memory Slots 4x288pin (DDR4)
Memory Standard Supports 1R 2133/2666/3200 MHz (by JEDEC & POR)

Max overclocking frequency:
– 1DPC 1R Max speed up to 5333+ MHz
– 1DPC 2R Max speed up to 4800+ MHz
– 2DPC 1R Max speed up to 4400+ MHz
– 2DPC 2R Max speed up to 4000+ MHz

Supports Dual-Channel mode
Supports non-ECC, un-buffered memory
Supports Intel Extreme Memory Profile (XMP)
Maximum Memory Supported 128GB
Channel Supported  Dual Channel
Expansion Slots
PCI Express 5.0 x16 PCI_E1 slot (From CPU)
– supports up to PCIe 5.0 x16
PCI Express 4.0 x16 PCI_E3 slot (From Z790 Chipset)
– supports up to PCIe 4.0 x4
PCI Express 3.0 x16 PCI_E4 slot (From Z790 Chipset)
– supports up to PCIe 3.0 x1
PCI Express x1 1x PCIe 3.0 x1 slot (From Z790 Chipset)
Storage Devices
SATA 6Gb/s  6x SATA 6Gb/s ports (From Z790 chipset)
M.2 2 x Key M (PCIe/SATA) + 2 x Key M (PCIe) + 1 x Key E (WiFi/BT)

4x M.2 slots (Key M)
M2_1 slot (From CPU)
– Supports up to PCIe 4.0 x4
– Supports 2242/2260/ 2280/ 22110 storage devices
M2_2 slot (From Z790 chipset)
– Supports up to PCIe 4.0 x4
– Supports 2242/ 2260/ 2280 storage devices
M2_3 & M2_4 slots (From Z790 chipset)
– Supports up to PCIe 4.0 x4
– Supports up to SATA 6Gb/s
– Supports 2242/ 2260/ 2280 storage devices

Supports Intel- Smart Response Technology for Intel Core-processors
SATA RAID Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices
Supports RAID 0, RAID 1, and RAID 5 for M.2 NVMe storage devices
Onboard Audio
Audio Chipset  Realtek ALC4080
Audio Channels  7.1 Channels
Onboard LAN
LAN Chipset 1x Intel 2.5Gbps LAN controller
Max LAN Speed 2.5Gbps
Wireless LAN Intel Wi-Fi 6
– The Wireless module is pre-installed in the M.2 (Key-E) slot
– Supports MU-MIMO TX/RX, 2.4GHz/ 5GHz (160MHz) up to 2.4Gbps
– Supports 802.11 a/ b/ g/ n/ ac/ ax
Bluetooth Supports Bluetooth 5.2
Rear Panel Ports
Back I/O Ports 1x DisplayPort
1x HDMI port
1x Flash BIOS button
2x USB 2.0 Type-A ports (From Hub GL850G)
2x USB 3.2 Gen1 5Gbps Type-A ports (From Z790 chipset)
1x LAN I225V port
3x USB 3.2 Gen 2 10Gbps Type-A ports (From Z790 chipset)
1x USB 3.2 Gen 2×2 20Gbps Type-C port (From Z790 chipset)
2x Wi-Fi Antenna connectors
5x Audio jacks
1x Optical S/PDIF Out connector
Internal I/O Connectors
Onboard USB 1x USB 3.2 Gen 2 10Gbps Type-C port (From Z790 chipset)
1x USB 3.2 Gen 1 5Gbps connector (From Z790 chipset)
– Support additional 2 USB 3.2 Gen 1 5Gbps ports
2x USB 2.0 Type-A connectors (From Hub GL850G)
– Supports additional 4 USB 2.0 ports
Other Connectors Fan Connectors
1x 4-pin CPU fan connector
1x 4-pin water-pump fan connector
6x 4-pin system fan connectors

System Connectors
1x Front panel audio connector
2x System panel connectors
1x Chassis Intrusion connector
1x TPM module connector
1x Tuning Controller connector
1x TBT connector (Supports RTD3)

Jumpers
1x Clear CMOS jumper

LED Features
1x 4-pin RGB LED connector
3x 3-pin ARGB Gen2 LED connectors
4x EZ Debug LED
Physical Spec
Form Factor ATX
LED Lighting RGB
Dimensions (W x L) 12.0″ x 9.6″
Power Pin 1x 24-pin ATX main power connector
2x 8-pin ATX 12V power connectors
Windows Compatibility
Windows 11 Supported
Features
Features MSI Center Features
– Gaming Mode
– Smart Priority
– Game Highlights
– Mystic Light
– Ambient Devices
– Frozr AI Cooling
– User Scenario
– True Color
– Live Update
– Monitor
– Super Charger
– Devices Speed Up
– Smart Image Finder
– MSI Companion
– System Diagnosis

Thermal Features
– Extended Heatsink Design
– M.2 Shield Frozr
– K7 MOSFET thermal pad / Extra choke pad
– Fan headers (CPU + PUMP + SYSTEM)

Performance
– Core Boost
– VRM Power Design (VCPU / VGT / AUX)
– Dual CPU Power (2x 8 pin)
– Memory Boost
– Lightning Gen 5 PCI-E Slot
– Lightning Gen 4 PCI-E / M.2 Slot
– Front USB Type-C
– Server PCB
– 2oz Copper thickened PCB

DIY Friendly
– PCI-E Steel Armor
– Pre-installed I/O Shield
– EZ M.2 Clips
– EZ DEBUG LED
– EZ LED Control (Switch)
– Flash BIOS Button

RGB Support
– Mystic Light Extension (RGB)
– Mystic Light Extension (A-RAINBOW V2)
– Ambient Devices Support
