Easy to Carry Around
With 15.6 inches screen, GT-156HD V2 has provided ample working area. It has a slim thickness which is only 15mm, plus 1.5kg weight, this device is portable. Easy to carry around, easy to set up your workplace anywhere.
Higher Precision
Upgraded from previous version’s 2048 levels, GT-156HD V2 has caught up to the new fashion and equipped with 8192 levels of pen pressure sensitivity. Heaviest stroke or lightest hairlines, you can rest and enjoy this amazing accuracy.
Eye-protective Screen
GT-156HD V2 has our own patented anti-glare glass, which has successfully get rid of screen protectors. Reduce harmful glare and provided a smooth paper-like texture, drawing on screen has been even more fun.
Convenient 3-in-1 Cable
3-in-1 cable saves more space and brings lesser mess. Also, the new mini HDMI interface on GT-156HD V2 has got a new strengthen design to avoid accidental unplugging.
Gorgeous Color
72% NTSC color gamut presents amazing color, vividly deliver your desired piece. Also to the better color configuration, push the center buttons on the bottom ring of express keys can bring out OSD functions.
Classy Ergo Stand
Different from other Huion’s pen displays, GT-156HD V2 comes with a two-section multi-angle adjustable stand, easy to adjust your favorite angle and easy to fold up when you don’t need it.
Compatibility
Windows 7/8/8.1/10, MAC OS 10.10 or late.
Specifications:
|
Product Name |
Kamvas GT-156HD V2 |
|
Product Model |
GT-156HD V2 |
|
Color |
Silver-gray |
|
Panel Size |
15.6 inch |
|
Resolution |
1920 x 1080 (16:9) |
|
LCD Type |
IPS |
|
Active Area |
344.2 × 193.6 mm |
|
Contrast Ratio |
41.66736111 |
|
Brightness |
220 cd/m2 |
|
Response Time |
30ms |
|
Viewing Angle |
89°/89°(H)/89°/89°(V) (Typ.)(CR＞10) |
|
Gamut |
72% NTSC |
|
Display Color |
262k (6bit) |
|
Pen Technology |
Active Electromagnetic Resonance |
|
Pen Resolution |
5080 LPI |
|
Pressure Levels |
8192 Levels |
|
Accuracy |
±0.5mm (Center), ±3mm (Corner) |
|
Reading Height |
12mm |
|
Report Rate |
233PPS |
|
Tilt Recognition |
– |
|
Finger Touch |
Touch Bar |
|
Digital Pen |
PE330 |
|
Input Voltage |
AC 100-240V, 50/60Hz |
|
Output Voltage |
12V 1A |
|
Video Interface |
HDMI |
|
Press Keys |
14 Programmable Press Keys |
|
Adjustable Stand |
ST200 |
|
OS Support |
Windows 7 or later, MacOS 10.11 or later |
|
AG Glass |
YES |
|
Full Lamination |
– |
|
Power Consumption |
≤8W |
|
Standby Consumption |
≤0.3W |
|
Working Temp. and Humidity |
0-40°C, 20-80% |
|
Storage Temp. and Humidity |
-20°C~60°C, 10-90% |
