AHD 1080P Rear View Camera for Chevrolet Vehicles

Pay now, in 4 interest-free payments of $3.97, or over 3–6 months

4 interest-free payments of $3.97

High-definition 1080P rear view camera with a 170° fisheye lens enhances safety for various Chevrolet models. Features night vision, IP68 waterproof rating, and supports both AHD and CVBS video signals.

Color Name

Voltage

Clear

↗

Estimated Delivery Time3–7 business days

Crystal clear 1080P rear view

Experience sharp high-definition video with advanced AHD technology. This camera uses Y/C signal separation, 3D noise reduction, and bright color separation to deliver clear images, reducing noise and enhancing image fidelity in real time.

Wide-angle fisheye lens for maximum coverage

Equipped with a 170° 6-glass fisheye lens, this camera captures a broad field of view to minimize blind spots and improve safety when reversing or parking.

170-degree viewing angle
6-glass fisheye lens for clarity
Reduces rear blind spots

Reliable night vision and waterproof design

Designed to perform in low light conditions with starlight night vision technology offering visibility beyond 10 meters. IP68 and IP69 waterproof ratings protect the camera from water and dust ingress for all-weather durability.

Starlight night vision with automatic adjustments
IP68/IP69 waterproof for harsh conditions

Versatile compatibility and robust performance

Compatible with multiple Chevrolet and Daewoo models across various years. It supports both AHD and CVBS video signals, making it adaptable to a wide range of monitor types. The camera works with 12V to 24V power supply and operates reliably between -30°C to +70°C.

Supports AHD and CVBS signals
Wide vehicle compatibility
Operates in extreme temperatures

Key specifications

Chip: OV2053HD
Resolution: AHD 1080P / CVBS 720P
Viewing Angle: 155°–175°
Lens: 14/16mm fisheye 6-glass
Waterproof rating: IP68/IP69
Power: DC 12V–24V, max 3W
Working temperature: -30°C to +70°C

What's in the box

AHD 1080P rear view camera unit

Product FAQ

Frequently asked questions

01 Which Chevrolet models is this rear view camera compatible with?

Compatible with Chevrolet Captiva (2006–2018), AVEO (T250) (2006–2011), Cruze sedan (2011–2014), Orlando (2010–2018), Spark (2005–2019), Epica/Tosca (2006–2013), and Daewoo Lacetti/Gentra/Nubira models.

02 What is the resolution of this rear view camera?

The camera supports high-definition AHD video at 1920x1080 pixels (PAL/25Hz) and CVBS video signal at 1280x720 pixels (NTSC/30Hz).

03 What is the viewing angle of the camera lens?

It features a wide 170-degree viewing angle using a 6-glass fisheye lens to provide a broad rear view.

04 Does this camera support night vision?

Yes, it offers starlight night vision with a visible distance greater than 10 meters, enhanced by automatic gain control, auto white balance, and backlight compensation.

05 Is the camera waterproof?

The camera is IP68 and IP69 rated for waterproof protection, suitable for various weather conditions.

06 What video signals does the camera support?

It supports both AHD and CVBS video signals, making it compatible with AHD Android monitors and all CVBS TFT monitors.

07 What are the power requirements for this camera?

The camera operates on DC 12V to 24V with a maximum power consumption of 3W.

08 What materials are used in the camera's construction?

The lens is made of plastic and glass materials, and the shell is constructed from durable plastic.

09 Is this camera resistant to extreme temperatures?

Yes, it is designed to work in temperatures ranging from -30°C to +70°C.

10 Are there any tips for installation or compatibility?

Check vehicle size compatibility before purchase, cut the white wire to switch from AHD to CVBS signal if needed, and ensure the DVD reverse trigger wire is correctly connected for proper operation.
