Corsair CX550 – 550 Watt 80 PLUS Bronze ATX Power Supply (IN) Price in Pakistan Specs
Key Specs
Total Connectors |
1x 24-Pin ATX Motherboard
1x 4+4-Pin EPS CPU 2x 6+2-Pin PCIe 3x 6-Pin SATA / Peripheral 2x 4-Pin Peripheral / Molex |
Cable Design |
Flat
|
Total Wattage |
550 W
|
Number of +12 V Rails |
1
|
Efficiency Rating |
80 PLUS Bronze
|
Form Factor |
ATX
|
Connectivity
Total Connectors |
1x 24-Pin ATX Motherboard
1x 4+4-Pin EPS CPU 2x 6+2-Pin PCIe 3x 6-Pin SATA / Peripheral 2x 4-Pin Peripheral / Molex |
Cable Design |
Flat
|
PCIe Connector Distances |
19.7″ / 500 mm
3.9″ / 100 mm |
SATA Connector Distances |
15.7″ / 400 mm
3.9″ / 100 mm 3.9″ / 100 mm |
Peripheral Connector Distances |
15.7″ / 400 mm
3.9″ / 100 mm |
ATX Connector Distance |
23.6″ / 600 mm
|
EPS Connector Distances |
23.6″ / 600 mm
|
Electrical
Total Wattage |
550 W
|
Number of +12 V Rails |
1
|
Combined Power for +12 V |
528 W
|
Max Load for +12 V |
44 A
|
Combined Power for +3.3/+5 V |
120 W
|
Max Load for +3.3 V |
24 A
|
Max Load for +5 V |
20 A
|
Max Power for +5 Vsb |
15 W
|
Max Load for +5 Vsb |
3 A
|
Max Power for -12 V |
3.6 W
|
Max Load for -12 V |
0.3 A
|
Input Power |
100 to 240 VAC, 50 / 60 Hz
|
General
Efficiency Rating |
80 PLUS Bronze
|
Active Power Factor Correction |
No
|
Efficiency |
88%
|
Cooling
Fan Size |
120 mm
|
Physical
Form Factor |
ATX
|
Mean Time Between Failures (MTBF) |
100,000 Hours
|
Dimensions |
4.9 x 3.4″ / 125 x 86 mm
|
