NVIDIA GeForce RTX 5090 – Specifications

• GPU: NVIDIA GeForce RTX 5090

• CUDA Cores: 21,760

• Video Memory: 32GB GDDR7

• Memory Bus: 512-bit

• Engine Clock: 2,422 MHz

• Memory Clock: 28 Gbps

• PCI Express: PCIe 5.0 x16

Display Outputs:

• 3 x DisplayPort 2.1b (UHBR20)

  • Supports up to 4K 480Hz or 8K 165Hz (with DSC)

• 1 x HDMI 2.1b

  • Supports 4K 120Hz HDR, 8K 60Hz HDR, and Variable Refresh Rate (VRR)

Additional Features:

• HDCP Support: 2.3

• Multi-Display Capability: Up to 4 displays

• DirectX: Microsoft DirectX® 12 Ultimate

• OpenGL: 4.6

Power & Cooling:

• Recommended Power Supply: 1000W

• Power Consumption: 575W (High power draw—please check your PSU manual before installation)

• Power Input: 1 x 12V-2×6 connector

• Cooling Solution: IceStorm 3.0

• Slot Size: 3.5 slots

Physical Dimensions:

• Card Size: 329.7mm (L) x 137.8mm (W) x 67.8mm (H)

  • (13″ x 5.4″ x 2.7″)

Included Accessories:

• User Manual

• 4 x 8-pin to 16-pin power cables

• SPECTRA LINK cable

• GPU Support Stand

Note: This card does not support SLI. Compatible with Windows 10 (64-bit, v1809 or later) and Windows 11.
