Form factor of the AIO cooler |
360mm |
|
CPU socket Specs |
|
|
Supported CPU models(intel) |
LGA 115X/1200/1366/1700/2011/2066 |
|
Supported CPU models(AMD) |
FM3/FM2/FM1/AM2/AM2+/AM3/AM3+/AM4/AM5 |
|
Fan Specs |
|
|
No of cooling fans Included |
3 x120mm ARGB Fans |
|
Noise level of the fan |
15-35db |
|
Power consumption of the Fan |
2.16W |
|
Rated Watts |
2.16W |
|
MTBF of the FAN |
30000 hours |
|
Speed of the Fan (max) |
1800RPM (max) |
|
Fan Dimensions(W xD x H) |
12x12x2.5 cm |
|
Type of fan connector used |
4 Pin Fan Connector |
|
RGB / ARGB Sync support |
ARGB Support |
|
Fan power connector and connector length |
4-Pin power Connector; Female – 49cm | Male – 56cm |
|
Fan LED connector and connector length |
3-Pin ARGB connector; Female -53.5cm | Male – 74.5cm |
|
PUMP specs |
|
|
Speed of the pump |
2500RPM±10% |
|
Rated Voltage of the Pump |
12V |
|
Rated current of the Pump |
0.3A |
|
Power consumption of the Pump |
3.6W |
|
Type of connector used |
3 Pin connector |
|
MTBF of the Pump |
30000 Hours |
|
Tube length of the AIO cooler |
38cm |
|
Type of Pipes used |
Braided rubber pipe |
|
Diameter of the Pipe |
1.2cm |
|
Noise level of the pump |
30db |
|
CPU Block power connector and connector length |
3-Pin Power connector; Length – 32cm |
|
CPU Block LED connector and connector length |
3-Pin ARGB connector; Female – 48cm | Male – 58cm |
|
Radiator Specs |
|
|
Material of the Heat Sink |
Aluminium |
|
Material of the Heat transfer Pipe |
Copper |
|
Dimension of the Radiator |
40 x 12 x 3cm |
|
Dimensions of the CPU Block |
9 x 7.5 x 5.2cm |
|
Package dimension |
21.5 x 14.5 x 46cm |
|
Product weight |
1.47kg |
|
Country of Origin |
People’s Republic of China |
|
Package Contents |
|
|
AIO cooler |
1U |
|
CPU mounting Brackets |
2U |
|
Backplate |
1U |
|
Screws Sets |
5U |
|
Thermal paste |
1U |
|
Thermal paste spreader |
1U |
|
QR code guide |
1U |
