Form factor of the AIO cooler |
360mm |
|
Supported CPU models(intel) |
LGA 115X/1200/1366/1700/2011/2066 |
|
Supported CPU models(AMD) |
FM3/FM2/FM1/AM2/AM2+/AM3/AM3+/AM4/AM5 |
|
Fan Specs |
|
|
No. of Fans |
3 x120mm |
|
Power Consumption |
2.16W |
|
Noise Level |
15-35db |
|
MTBF |
30000 Hours |
|
Airflow Rate |
67.96 CFM |
|
Speed (Max.) |
1800RPM |
|
RGB / ARGB Sync |
ARGB Support |
|
Power Connector |
4-Pin | Length : 50cm |
|
LED Connector |
3-Pin | Length : 52cm |
|
Dimensions (W xD x H) |
12 x 12 x 2.5 cm |
|
PUMP specs |
|
|
Pump USB |
4-Pin | Length : 74cm |
|
Rated Voltage / Current |
12V / 0.3A |
|
Power Consumption |
3.6W |
|
Noise Level |
30db |
|
MTBF |
30000 Hours |
|
Speed (Max.) |
2500RPM |
|
|
|
|
Tube Type |
Braided Rubber Tube |
|
Tube Length |
38cm |
|
Tube Diameter |
1.2cm |
|
Power Connector |
 3-Pin | Length : 32cm |
|
LED Connector |
3-Pin | Length : 47.5cm |
|
Dimensions (W xD x H) |
9.5 x 9 x 5.2cm |
|
Radiator Specs |
|
|
Material of the Heat Sink |
Aluminium |
|
Material of the Heat transfer Pipe |
Aluminium |
|
Dimensions (W xD x H) |
39.5 x 12 x 2.7cm |
|
Net weight |
1.4 kg |
|
Country of Origin |
PRC |
|
|
|
|
|
|
|
Package Contents |
|
|
AIO cooler |
1U |
|
AMD Bracket |
1U |
|
Intel Backplate |
1U |
|
Screws Sets |
5U |
|
Thermal Paste with Spreader |
1U |
|
QR Code Guide |
1U |
